LED Floodlight BVP008 10W 3000K 900lm PILA

Adjustability

Rotatable

Beam angle

Extreme wide beam >80°

Beam angle adjustable

No

Built-in height/depth

- mm

Built-in length

- mm

Built-in width

- mm

Colour consistency (McAdam ellipse)

SDCM6

Colour housing

Black

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

3000 .. 3000 K

Colour temperature

3000 K

Colour temperature adjustable

No

Compatible with Amazon Alexa

-

Compatible with Apple HomeKit

-

Compatible with Google Assistant

-

Conductor cross section

1 mm²

Connectable conductor cross section

1.0 .. 1.0 mm²

Connection type

Other

Constant luminous flux control

-

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP65

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

-

Dimming DALI-2

-

Dimming DMX

-

Dimming DSI

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

-

Dimming with push-button

-

Emergency power supply integrated

-

Energy efficiency class of the light source according to EU regulation 2019/2015

F

Exchangeable control gear

-

Failure rate at median useful life of 35,000 h at 25 °C ambient (tq)

7.5 %

Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)

- %

Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)

- %

Filament test according to IEC 60695-2-11

650 °C - 30 s

Fit for monitor workplace acc. EN 12464-1

-

Flickering value Pst LM

1

Height/depth

28 mm

IFTTT support available

-

Impact strength

IK06

Lamp holder

Other

Lamp type

LED not exchangeable

Length

107 mm

Light distributor

Reflector

Light outlet

Direct

Light sharing

Symmetric

Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)

65 %

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)

- %

Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)

- %

Luminaire efficacy

90 lm/W

Luminaire with limited surface temperature, sign "D“

-

Luminous flux

900 .. 900 lm

Luminous flux adjustable

No

Luminous intensity

- cd

Material cover

Glass transparent

Material housing

Aluminium

Max. number of luminaires per miniature circuit breaker B16 (MCB)

218

Max. number of luminaires per miniature circuit breaker C16 (MCB)

254

Max. system power

10 W

No dim function

+

Nominal current

33 .. 33 mA

Nominal voltage

220 .. 240 V

Number of poles

3

Operation by Bluetooth

-

Outer diameter

- mm

Photobiological safety according to EN 62471

RG1

Power factor

0.9

Protection class

I

Rated ambient temperature acc. IEC62722-2-1

25 .. 25 °C

Rated life time L70/B50 at 25 °C

- h

Rated luminous flux acc. IEC 62722-2-1

900 lm

Reflector

Other

Reflector colour

White

Stroboscope effect value SVM

1.6

Suitable for built-in mounting

-

Suitable for ceiling mounting

-

Suitable for clamp-mounting

-

Suitable for light-track mounting

-

Suitable for low voltage cable system

-

Suitable for number of lamps

1

Suitable for pedestal/floor mounting

+

Suitable for surface mounting

+

Suitable for suspended mounting

-

Suitable for traverse mounting

-

Surface brushed

-

Surface protection

Powder coating

Total harmonic distortion

20

Type of control gear

LED operating device current-controlled

Type of wiring

Ending

Unified Glare Ratio (UGR)

30

Voltage type

AC

Wall mounting

-

Width

102 mm

With light sensor

-

With light source

+

With movement sensor

-
