if you buy 1-9
61.41 € / pcs.
if you buy 10-19
52.20 € / pcs.
if you buy 20+
49.13 € / pcs.
Quantity
Total price VAT included (21%)
Riga (Marupe)
37
Daugavpils
0
Valmiera
10
Ventspils
0
Manufacturer
Manufacturers ID
911401823980
EAN
8710163346366
Net Weight
2.32 kg
Colour
Gray
Dimensions
1515X80X76 mm
Dimmable
No
Impact protection
IK08
Ingress Protection
IP65
LED
Yes
Lifetime L70B50
50000 h
Luminaire output
8000 Lm
Power
57.1 W
Product series
CoreLine waterproof
System efficacy
140 Lm/W
Beam angle
Extreme wide beam >80°
Beam angle adjustable
No
Built-in diameter
- mm
Built-in height/depth
1515 mm
Built-in length
- mm
Built-in width
- mm
Colour consistency (McAdam ellipse)
SDCM3
Colour housing
Grey
Colour of light
White
Colour rendering index CRI
80-89
Colour temperature
4000 K
Colour temperature
4000 .. 4000 K
Colour temperature adjustable
No
Conductor cross section
0.5 mm²
Connection type
Push-in clamp
Constant luminous flux control
-
Control gear included
+
Covering of the luminaire with thermally insulating material possible
+
Degree of protection (IP)
IP65
Dimming 0-10 V
-
Dimming 1-10 V
-
Dimming DALI
-
Dimming DMX
-
Dimming DSI
-
Dimming GPRS
-
Dimming LineSwitch
-
Dimming RF
-
Dimming Sine Wave Reduction
-
Dimming Touch and Dim
-
Dimming Zigbee
-
Dimming depending on control gear
-
Dimming mains voltage modulation
-
Dimming manufacturer's proprietary system
-
Dimming phase cut-off
-
Dimming phase cut-on
-
Dimming potentiometer (integrated)
-
Dimming programmable
-
Dimming with push-button
-
Emergency power supply integrated
-
Energy Efficiency Index (EEI)
-
Filament test according to IEC 60695-2-11
850 °C - 30 s
Fit for monitor workplace acc. EN 12464-1
-
Height/depth
76 mm
Housing surface protection
Untreated
IFTTT support available
-
Impact strength
IK08
Lamp holder
Other
Lamp type
LED not exchangeable
Length
1515 mm
Light distributor
Diffuser lens/optic/panel
Light outlet
Direct
Light sharing
Symmetric
Luminaire efficacy
140 lm/W
Luminaire with limited surface temperature, sign "D“
+
Luminous flux adjustable
No
Luminous intensity
- cd
Material cover
Plastic matt/satinized
Material housing
Plastic
Max. system power
57.1 W
No dim function
+
Nominal current
290 .. 290 mA
Nominal voltage
220 .. 240 V
Number of poles
3
Outer diameter
- mm
Photobiological safety according to EN 62471
RG0
Power factor
0.9
Protection class
I
Rated ambient temperature acc. IEC62722-2-1
25 .. 25 °C
Rated life time L70/B50 at 25 °C
75000 h
Rated life time L80/B10 at 25 °C
- h
Rated life time L90/B10 at 25 °C
- h
Rated luminous flux acc. IEC 62722-2-1
8000 lm
Suitable for built-in mounting
-
Suitable for ceiling mounting
+
Suitable for emergency lighting
-
Suitable for light line configuration
-
Suitable for number of lamps
1
Suitable for surface mounting
+
Suitable for suspended mounting
+
Suitable for wall mounting
+
Total harmonic distortion
20
Type of control gear
LED operating device current-controlled
Type of grid
None
Type of wiring
Suitable for through wiring
Voltage type
AC
Width
80 mm
With air slots
-
With light sensor
-
With light source
+
With movement sensor
-
