LED panel COMPACT 1200V 33W 3630lm 4000K 110lm/W 840 white

Beam angle

Open beam/diffuse

Beam angle adjustable

No

Built-in diameter

- mm

Built-in height/depth

50 mm

Built-in length

1190 mm

Built-in width

290 mm

Colour consistency (McAdam ellipse)

SDCM5

Colour housing

White

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

4000 .. 4000 K

Colour temperature

4000 K

Colour temperature adjustable

No

Conductor cross section

- mm²

Connection type

Push-in clamp

Constant luminous flux control

-

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP40

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

-

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming depending on control gear

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

-

Dimming with push-button

-

Emergency power supply integrated

-

Energy Efficiency Index (EEI)

-

Fit for monitor workplace acc. EN 12464-1

-

Height/depth

50 mm

IFTTT support available

-

Impact strength

IK02

Length

1195 mm

Light distributor

Diffuser lens/optic/panel

Light outlet

Direct

Luminaire efficacy

110 lm/W

Luminaire with limited surface temperature, sign "D“

-

Luminous flux adjustable

No

Luminous intensity

- cd

Material housing

Aluminium

Max. system power

33 W

No dim function

+

Nominal current

150 .. 150 mA

Nominal voltage

220 .. 240 V

Number of poles

2

Outer diameter

- mm

Photobiological safety according to EN 62471

RG0

Power factor

-

Protection class

II

Rated ambient temperature acc. IEC62722-2-1

-10 .. 45 °C

Rated life time L70/B50 at 25 °C

70000 h

Rated life time L80/B10 at 25 °C

50000 h

Rated life time L90/B10 at 25 °C

40000 h

Rated luminous flux acc. IEC 62722-2-1

3630 lm

Suitable for built-in mounting

+

Suitable for ceiling mounting

+

Suitable for emergency lighting

+

Suitable for light line configuration

-

Suitable for number of lamps

-

Suitable for surface mounting

+

Suitable for suspended mounting

+

Suitable for wall mounting

-

Total harmonic distortion

-

Type of grid

Matt

Type of wiring

Suitable for through wiring

Voltage type

AC

Width

295 mm

With air slots

-

With light sensor

-

With light source

+

With movement sensor

-
