High-bay luminaire DALI GEN 3 155W 4000K 110 ° IP65

Ball-proof

-

Beam angle

Open beam/diffuse

Beam angle adjustable

No

Built-in diameter

- mm

Built-in height/depth

- mm

Built-in length

- mm

Built-in width

- mm

Colour housing

Black

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

4000 .. 4000 K

Colour temperature

4000 K

Colour temperature adjustable

No

Conductor cross section

- mm²

Constant luminous flux control

-

Control gear included

+

Degree of protection (IP)

IP65

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

+

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

-

Dimming with push-button

-

Emergency power supply integrated

-

Energy efficiency class of the built-in lamp

A++, A+, A (LED)

Filament test according to IEC 60695-2-11

850 °C - 30 s

Height/depth

163 mm

Impact strength

IK08

LED nominal current at constant current

700 .. 700 mA

Lamp type

LED not exchangeable

Length

- mm

Light distributor

None

Light sharing

Symmetric

Luminaire efficacy

140 lm/W

Luminaire with limited surface temperature, sign "D“

-

Luminous flux adjustable

No

Material housing

Aluminium

Material reflector

Without reflector

Max. system power

155 W

No dim function

-

Nominal current

700 .. 700 mA

Nominal voltage

100 .. 277 V

Number of poles

5

Outer diameter

321 mm

Power factor

0.95

Protection class

I

Rated ambient temperature acc. IEC62722-2-1

-30 .. +50 °C

Rated life time L70/B10 at 25 °C

80000 h

Rated life time L70/B50 at 25 °C

80000 h

Rated life time L80/B10 at 25 °C

50000 h

Rated life time L80/B50 at 25 °C

50000 h

Rated life time L90/B10 at 25 °C

30000 h

Rated life time L90/B50 at 25 °C

30000 h

Rated luminous flux acc. IEC 62722-2-1

22000 lm

Reflector

None

Suitable for auxiliary lamp

-

Suitable for emergency lighting

-

Suitable for number of lamps

0

Total harmonic distortion

-

Type of control gear

Electronic ballast

Type of wiring

Ending

Voltage type

AC

Width

- mm

With light source

+

With protective cover

+
