DILM7-01 Contactor 230V50Hz 240V60Hz 3P AC

Modular version

-

Number of auxiliary contacts as normally closed contact

1

Number of auxiliary contacts as normally open contact

0

Number of main contacts as normally open contact

3

Number of normally closed contacts as main contact

0

Rated control supply voltage Us at AC 50HZ

230 .. 230 V

Rated control supply voltage Us at AC 60HZ

240 .. 240 V

Rated control supply voltage Us at DC

0 .. 0 V

Rated operation current Ie at AC-1, 400 V

22 A

Rated operation current Ie at AC-3, 400 V

7 A

Rated operation current Ie at AC-4, 400 V

5 A

Rated operation power NEMA

2.2 kW

Rated operation power at AC-3, 400 V

3 kW

Rated operation power at AC-4, 400 V

2.2 kW

Type of electrical connection of main circuit

Screw connection

Voltage type

AC

Voltage type for actuating

AC
