LCD Monitor DAHUA 23.6 " 1920 x 1080 pixels Full HD Native aspect ratio 16:9 LED Curved DHI-LM24-E240C

Net Weight

3.6 kg

AC adapter output voltage

12 V

AMD FreeSync

-

Automatic brightness control

-

Backlight type

Edge LED

Bezel width (bottom)

16.4 mm

Bezel width (side)

3.2 mm

Bezel width (top)

3.2 mm

Bluetooth

-

Built-in USB hub

-

Built-in camera

-

Built-in speaker(s)

-

Cables included

DisplayPort

Colour depth

8 bit

Colour gamut standard

NTSC

Compliance certificates

CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)

Contrast ratio (typical)

3000:1

Data Sheet (Link)

https://eprel.ec.europa.eu/api/product/2398044/fiches?language=EN

Depth (without stand)

90.7 mm

Depth (with stand)

202.2 mm

Detachable stand

+

DisplayPorts quantity

1

DisplayPort version

1.4

Display brightness (typical)

350

Display diagonal

23.6

Display diagonal (metric)

60 cm

Display resolution

1920

Display technology

LED

EPREL Registration Number

2398044

EPREL Version Number

1

Energy consumption (HDR) per 1000 hours

25

Energy consumption (SDR) per 1000 hours

17

Energy efficiency class

E

Energy efficiency class (HDR)

G

Energy efficiency class (SDR)

E

Energy efficiency scale

A to G

Feet colour

Black

Flicker-free technology

+

Frameless design

+

Front bezel colour

Black

HDMI

+

HDMI ports quantity

1

HDMI version

2.0

HD type

Full HD

Headphone out

+

Height (without stand)

320.3 mm

Height (with stand)

414.5 mm

High Dynamic Range (HDR) supported

+

High Dynamic Range (HDR) technology

High Dynamic Range 10 (HDR10)

Illuminated stand

-

Input current

3

LED backlight

+

Low Blue Light technology

+

Manual

+

Market positioning

Gaming

Maximum refresh rate

240

NTSC coverage (typical)

85

NVIDIA G-SYNC

-

Native aspect ratio

16:9

Operating relative humidity (H-H)

10

Operating temperature (T-T)

0

Package depth

145 mm

Package height

400 mm

Package weight

4200 g

Package width

623 mm

Panel mounting interface

100 mm

Panel type

VA

Pixel density

93.3

Pixel pitch

0.2716 mm

Plug and Play

+

Power adapter included

+

Power consumption (max)

34

Power consumption (off)

0.3

Power consumption (standby)

0.5

Power consumption (typical)

24

Power supply type

External

Product colour

Black

Response time (MPRT)

1 ms

Screen curvature rating

1500R

Screen shape

Curved

Stand included

+

Storage relative humidity (H-H)

5

Storage temperature (T-T)

-20

Summary

Dahua Technology LM24-E240C. Display diagonal: 59.9 cm (23.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mount

Supported graphics resolutions

1920 x 1080 (HD 1080)

Supported video modes

1080p

Surface hardness

3H

Tilt adjustment

+

Tilt angle range

-5

Touchscreen

-

Unit Calculated Volume

0.036 cubm

VESA mounting

+

Vendor Homepage

https://www.dahuasecurity.com/fr/products/All-Products/Display--Control/Monitors/Gaming-Series/LM24-E240C=V1

Viewable size, horizontal

521.395 mm

Viewable size, vertical

296.285 mm

Viewing angle, horizontal

178

Viewing angle, vertical

178

Wall mountable

+

Weight (without stand)

3600 g

Wi-Fi

-

Width (without stand)

537.9 mm

Width (with stand)

537.9 mm
