ORBIS CLICK SENSOR 430 50W

Beam angle

Extreme wide beam >80°

Built-in diameter

- mm

Built-in height/depth

- mm

Built-in length

- mm

Built-in width

- mm

Colour housing

White

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

3000 .. 3000 K

Colour temperature adjustable

No

Conductor cross section

- mm²

Connection type

Push-in clamp

Constant luminous flux control

-

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP20

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

-

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming depending on control gear

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

-

Dimming with push-button

-

Emergency power supply integrated

-

Energy Efficiency Index (EEI)

-

Energy efficiency class of the built-in lamp

A++, A+, A (LED)

Fit for monitor workplace acc. EN 12464-1

-

Height/depth

80 mm

IFTTT support available

-

Lamp type

LED not exchangeable

Length

430 mm

Luminaire efficacy

74 lm/W

Luminaire with limited surface temperature, sign "D“

-

Luminous flux adjustable

No

Luminous intensity

- cd

Material cover

Plastic matt/satinized

Material housing

Steel

Max. system power

50 W

No dim function

+

Nominal voltage

220 .. 240 V

Number of poles

-

Outer diameter

- mm

Plotis

430 mm

Power factor

0.7

Protection class

II

Rated ambient temperature acc. IEC62722-2-1

-20 .. 40 °C

Rated life time L70/B50 at 25 °C

30000 h

Rated life time L80/B10 at 25 °C

- h

Rated life time L90/B10 at 25 °C

- h

Rated luminous flux acc. IEC 62722-2-1

3700 lm

Suitable for built-in mounting

-

Suitable for ceiling mounting

+

Suitable for emergency lighting

-

Suitable for light line configuration

-

Suitable for number of lamps

-

Suitable for surface mounting

+

Suitable for suspended mounting

-

Suitable for wall mounting

-

Total harmonic distortion

-

Type of control gear

Electronic ballast

Type of grid

Matt

Voltage type

AC

With air slots

-

With light sensor

+

With light source

-

With movement sensor

+
