Ceiling-/wall luminaire

Beam angle

Extreme wide beam >80°

Colour housing

White

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

3000 .. 3000 K

Connection type

Other

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP54

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

+

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming depending on control gear

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

+

Dimming with push-button

-

Energy efficiency class of the built-in lamp

A++, A+, A (LED)

Filament test according to IEC 60695-2-11

650 °C - 30 s

Fit for monitor workplace acc. EN 12464-1

-

Impact strength

IK03

Lamp holder

Other

Lamp type

LED not exchangeable

Length

110 mm

Light distributor

None

Light outlet

Direct

Light sharing

Symmetric

Luminaire efficacy

101.05 lm/W

Luminaire with limited surface temperature, sign "D“

-

Material cover

Plastic, opal

Material housing

Plastic

No dim function

-

Nominal voltage

220 .. 240 V

Protection class

II

Rated ambient temperature acc. IEC62722-2-1

10 .. 40 °C

Rated luminous flux acc. IEC 62722-2-1

960 lm

Suitable for built-in mounting

-

Suitable for ceiling mounting

+

Suitable for emergency lighting

-

Suitable for lamp power

9.5 .. 9.5 W

Suitable for light line configuration

-

Suitable for surface mounting

+

Suitable for suspended mounting

-

Suitable for wall mounting

+

Type of control gear

LED operating device current-controlled

Type of grid

None

With air slots

-

With light sensor

+

With light source

+

With movement sensor

+
