Złączka przelotowa WLZ35/5x16/sssnz

Aukščio

37 mm

Closing plate required

-

Connectable conductor cross section fine-strand with cable end sleeve

1.5 .. 16 mm²

Connectable conductor cross section fine-strand without cable end sleeve

1.5 .. 16 mm²

Connectable conductor cross section multi-wired

1.5 .. 16 mm²

Connectable conductor cross section solid-core

1.5 .. 16 mm²

Depth

40 mm

Explosion-tested version 'Ex e'

-

Internally connected stages

-

Number of clamp positions per level

2

Number of levels

5

Plotis

61 mm

Rated current In

75 A

Rated voltage

690 V

Spalva

Multi-coloured

Suitable for conductor material

Aluminium/copper

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection
