Złączka przelotowa WLZ35/3x95/s

Aukščio

60.5 mm

Closing plate required

-

Connectable conductor cross section fine-strand with cable end sleeve

16 .. 95 mm²

Connectable conductor cross section fine-strand without cable end sleeve

16 .. 95 mm²

Connectable conductor cross section multi-wired

16 .. 95 mm²

Connectable conductor cross section solid-core

16 .. 95 mm²

Depth

41.5 mm

Explosion-tested version 'Ex e'

-

Internally connected stages

-

Mounting method

DIN rail (top hat rail) 35 mm

Number of clamp positions per level

6

Number of levels

1

Plotis

87 mm

Rated current In

220 A

Rated voltage

690 V

Spalva

Pilka

Suitable for conductor material

Aluminium/copper

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection
