Złączka przelotowa WLZ35/3x50/s

Aukščio

0.0485 mm

Closing plate required

-

Connectable conductor cross section fine-strand with cable end sleeve

2.5 .. 50 mm²

Connectable conductor cross section fine-strand without cable end sleeve

2.5 .. 50 mm²

Connectable conductor cross section multi-wired

2.5 .. 50 mm²

Connectable conductor cross section solid-core

2.5 .. 50 mm²

Depth

0.031 mm

Explosion-tested version 'Ex e'

-

Internally connected stages

-

Mounting method

DIN rail (top hat rail) 35 mm

Number of clamp positions per level

6

Number of levels

1

Plotis

0.049 mm

Rated current In

145 A

Rated voltage

690 V

Spalva

Pilka

Suitable for conductor material

Aluminium/copper

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection
