Złączka przelotowa/dwutorowa WLZ35/2x150/n

Aukščio

59 mm

Closing plate required

-

Connectable conductor cross section fine-strand with cable end sleeve

120 .. 150 mm²

Connectable conductor cross section fine-strand without cable end sleeve

120 .. 150 mm²

Connectable conductor cross section multi-wired

120 .. 150 mm²

Connectable conductor cross section solid-core

120 .. 150 mm²

Depth

52 mm

Explosion-tested version 'Ex e'

-

Internally connected stages

+

Mounting method

DIN rail (top hat rail) 35 mm

Number of clamp positions per level

4

Number of levels

1

Plotis

95 mm

Rated current In

290 A

Rated voltage

600 V

Spalva

Mėlyna

Suitable for conductor material

Aluminium/copper

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection
