Listwa N+PE stostowana w rozdzielnicach RH NEOseries

Aukščio

26 mm

Be halogenų

+

Closing plate required

+

Connectable conductor cross section fine-strand with cable end sleeve

1.5 .. 16 mm²

Connectable conductor cross section solid-core

1.5 .. 16 mm²

Depth

18 mm

Drill hole distance centrically

137 mm

Explosion-tested version 'Ex e'

-

Material insulation body

Thermoplastic

Mounting method

Direct mounting

Number of clamp positions per pole

7

Number of poles

2

Operation temperature

-20 .. 60 °C

Plotis

155 mm

Rated current In

120 A

Rated voltage

500 V

Spalva

Other

Transparent

-

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection
