Linergy passthrough terminal block, 4mm2 32A single-level 2x2 spring, grey. range: Linergy - product name: TR - product or component type: terminal block - device short name: TRR - terminal block type: passthrough - mounting mode: clip-on - nominal c

Closing plate required

+

Connectable conductor cross section fine-strand with cable end sleeve

0.2 .. 4 mm²

Connectable conductor cross section fine-strand without cable end sleeve

0.08 .. 4 mm²

Connectable conductor cross section multi-wired

0.08 .. 4 mm²

Connectable conductor cross section solid-core

0.08 .. 6 mm²

Connection position

Atop

Explosion-tested version 'Ex e'

+

Height at lowest possible mounting height

36.5 mm

Inflammability class of insulation material acc. with UL94

V0

Internally connected stages

-

Length

87 mm

Material insulation body

Thermoplastic

Mounting method

DIN rail (top hat rail) 35 mm

Number of clamp positions per level

4

Number of levels

1

Operation temperature

-40 .. 130 °C

Rated current In

32 A

Rated voltage

800 V

Type of electrical connection 1

Spring clamp connection

Type of electrical connection 2

Spring clamp connection

Width/grid dimension

6.2 mm

Цвет

Серый
