ZKMZGEL145 Złączka kablowa do mufy 3x1,5-6mm²

Closing plate required

-

Connectable conductor cross section fine-strand with cable end sleeve

1.5 .. 6 mm²

Connectable conductor cross section fine-strand without cable end sleeve

1.5 .. 6 mm²

Connectable conductor cross section multi-wired

1.5 .. 6 mm²

Connectable conductor cross section solid-core

1.5 .. 6 mm²

Depth

20 mm

Explosion-tested version 'Ex e'

-

Internally connected stages

-

Material insulation body

Thermoplastic

Mounting method

Direct mounting

Number of clamp positions per level

2

Number of levels

3

Rated current In

- A

Rated voltage

- V

Suitable for conductor material

Copper

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection

Высота

45 mm

Цвет

Black

Ширина

20 mm
