NUMINOS PROJECTOR XS recessed ceiling light, 2700 K, 40°, cylindrical, white / white

Adjustability

Swivelling

Beam angle

Medium beam 21-40°

Beam angle adjustable

No

Built-in height/depth

100 mm

Built-in length

68 mm

Built-in width

68 mm

Colour housing

White

Colour of light

White

Colour rendering index CRI

90-100

Colour temperature

2700 .. 2700 K

Colour temperature adjustable

No

Conductor cross section

- mm²

Constant luminous flux control

-

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP20

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

-

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming depending on control gear

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

-

Dimming with push-button

-

Emergency power supply integrated

-

Fit for monitor workplace acc. EN 12464-1

+

Height/depth

49 mm

IFTTT support available

-

LED nominal current at constant current

200 .. 200 mA

Laius

49 mm

Lamp holder

Other

Lamp type

LED not exchangeable

Length

80 mm

Light distributor

Other

Light outlet

Direct

Light sharing

Symmetric

Luminaire efficacy

- lm/W

Luminaire with limited surface temperature, sign "D“

-

Luminous flux

650 .. 650 lm

Luminous flux adjustable

No

Luminous intensity

- cd

Material cover

Other

Material housing

Aluminium

Max. system power

- W

No dim function

+

Nominal current

200 .. 200 mA

Number of poles

-

Outer diameter

49 mm

Power factor

-

Protection class

III

Rated ambient temperature acc. IEC62722-2-1

-20 .. 40 °C

Rated life time L70/B50 at 25 °C

50000 h

Rated life time L80/B10 at 25 °C

- h

Rated luminous flux acc. IEC 62722-2-1

650 lm

Reflector

Other

Reflector colour

Silver

Suitable for built-in mounting

+

Suitable for ceiling mounting

+

Suitable for clamp-mounting

+

Suitable for light-track mounting

-

Suitable for low voltage cable system

-

Suitable for number of lamps

1

Suitable for pedestal/floor mounting

-

Suitable for surface mounting

-

Suitable for suspended mounting

-

Suitable for traverse mounting

-

Surface brushed

-

Surface protection

Lacquered

Total harmonic distortion

-

Type of control gear

LED operating device current-controlled

Type of wiring

Ending

Voltage type

DC

Wall mounting

-

With light sensor

-

With light source

+

With movement sensor

-
