Motor protection circuit breaker 3P 0.16-0.25A ; 0.03/0.06 kW at 230/415V

Adjustment range undelayed short-circuit release

3.1 .. 4.7 A

Degree of protection (IP)

IP20

Depth

75 mm

Device construction

Built-in device fixed built-in technique

Kõrgus

140 mm

Laius

45 mm

Number of poles

3

Overload release current setting

0.16 .. 0.25 A

Phase failure sensitive

+

Rated operating voltage

690 .. 690 V

Rated operation power at AC-3, 230 V

- kW

Rated operation power at AC-3, 400 V

0.06 kW

Rated permanent current Iu

0.25 A

Rated short-circuit breaking capacity lcu at 400 V, AC

150 kA

Switch off technique

Thermomagnetic

Type of control element

Turn button

Type of electrical connection of main circuit

Screw connection

With integrated auxiliary switch

-

With integrated under voltage release

-

With thermal protection

+
