Ceiling-/wall luminaire

Beam angle

Extreme wide beam >80°

Colour housing

Anthracite

Colour of light

White

Colour rendering index CRI

80-89

Colour temperature

4000 .. 4000 K

Connection type

Other

Control gear included

+

Covering of the luminaire with thermally insulating material possible

-

Degree of protection (IP)

IP44

Dimming 0-10 V

-

Dimming 1-10 V

-

Dimming DALI

-

Dimming DMX

-

Dimming DSI

-

Dimming GPRS

-

Dimming LineSwitch

-

Dimming RF

-

Dimming Sine Wave Reduction

-

Dimming Touch and Dim

-

Dimming Zigbee

-

Dimming depending on control gear

-

Dimming mains voltage modulation

-

Dimming manufacturer's proprietary system

-

Dimming phase cut-off

-

Dimming phase cut-on

-

Dimming potentiometer (integrated)

-

Dimming programmable

+

Dimming with push-button

-

Energy efficiency class of the built-in lamp

A++, A+, A (LED)

Filament test according to IEC 60695-2-11

650 °C - 30 s

Fit for monitor workplace acc. EN 12464-1

-

Height/depth

298 mm

Impact strength

IK03

Laius

189 mm

Lamp holder

Other

Lamp type

LED not exchangeable

Length

187 mm

Light distributor

None

Light outlet

Direct

Light sharing

Symmetric

Luminaire efficacy

125 lm/W

Luminaire with limited surface temperature, sign "D“

-

Material cover

Plastic, transparent

Material housing

Plastic

No dim function

-

Number of poles

0

Protection class

III

Rated ambient temperature acc. IEC62722-2-1

-20 .. 40 °C

Rated luminous flux acc. IEC 62722-2-1

150 lm

Suitable for built-in mounting

-

Suitable for ceiling mounting

-

Suitable for emergency lighting

-

Suitable for lamp power

1.2 .. 1.2 W

Suitable for light line configuration

-

Suitable for surface mounting

+

Suitable for suspended mounting

-

Suitable for wall mounting

+

Type of control gear

LED operating device current-controlled

Type of grid

None

Voltage type

DC

With air slots

-

With light sensor

+

With light source

+

With movement sensor

+
