Potenciālu izlidzīnoša kopne BigBar/5+5 CU savienojumi 5+5 x M10, Cu

Construction type

Surface mounting fix

Explosion-tested version

-

Insulator

+

Kõrgus

85 mm

Laius

40 mm

Length

605 mm

Material of clamp

Copper

Material of contact rail

Copper

Model

Only clamp

Number of connections conductor to 6 mm² fixed

0

Number of connections conductor to 16 mm² fixed

0

Number of connections conductor to 25 mm² fixed

0

Number of connections conductor to 95 mm² fixed

0

Number of connections flat conductor 30 mm

0

Number of connections flat conductor 40 mm

0

Number of connections round conductor 8 mm

0

Number of connections round conductor 8-10 mm

0

Number of connections round conductor 10 mm

0

Number of connections round conductor total

-

Surface of the clamp

Untreated

Surface of the contact rail

Untreated
