WRL ROUTER LTE CAT 6/RUT261 TELTONIKA

4G LTE category

6

4G standard

LTE

Antenna connector type

SMA/RP-SMA

Antennas quantity

3

Antenna type

External

Authentication method

Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator

Auto MDI/MDI-X

+

Bluetooth

-

Built-in display

-

Built-in processor

+

Card reader integrated

-

Certification

E-Mark, UCRF

Compliance certificates

CB/CE/EAC/RCM/REACH/RoHS/UKCA

Country of origin

Lithuania

DHCP client

+

DHCP server

+

Data network

3G/4G

Data transfer rate (LTE) (download)

300

Data transfer rate (LTE) (upload)

50

Depth

74 mm

Device type

Cellular network router

Doesn't contain

Cadmium/Lead/Mercury

Dynamic DNS (DDNS)

+

Ethernet LAN

+

Ethernet LAN (RJ-45) ports

2

Ethernet LAN data rates

10

Ethernet LAN interface type

Fast Ethernet

Firewall

+

Height

25 mm

Housing material

Aluminium/Plastic

IP routing

+

Input voltage

9 V

Internal storage capacity

0.032 GB

International Protection (IP) code

IP30

LED indicators

LAN/Power/Status/WAN

MAC address filtering

+

Management protocols

HTTP(S), MQTT, Azure MQTT

Market positioning

Business

Model name

RUT261

Mounting

DIN-rail/Wall mounting

Network bridge

+

Networking standards

IEEE 802.11e/IEEE 802.11k/IEEE 802.11r/IEEE 802.11s/IEEE 802.11v/IEEE 802.1x/IEEE 802.3/IEEE 802.3az/IEEE 802.3u

Number of SIM cards

1

Number of WLAN connections (max)

50

Number of simultaneous SIM cards

1

Operating relative humidity (H-H)

10

Operating system installed

RutOS

Operating temperature (T-T)

-40

Package depth

148 mm

Package height

71 mm

Package width

173 mm

Power consumption (max)

3.5

Power source type

DC,PoE

Processor manufacturer

Mediatek

Product colour

Black

RAM capacity

0.128 GB

RAM type

DDR2

Reset button

+

SIM card type

MiniSIM

Security algorithms

128-bit AES/192-bit AES/256-bit AES/3DES/DES/SSID

Short Message Service (SMS)

+

Summary

Teltonika RUT261. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11s, IEEE 802.11r,

Supported network protocols

TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN

USB port

-

Unit Box Height

0.07

Unit Box Length

0.153

Unit Box Width

0.15

Unit Calculated Volume

0.003308 cubm

Units per Pallet

0

VPN Passthrough

+

Vendor Homepage

https://www.teltonika-networks.com/products/routers/rut261

VoIP

+

Waste Electrical and Electronic Equipment (WEEE) compliance

+

Weight

132 g

Wi-Fi

+

Wi-Fi standards

802.11b/802.11g/Wi-Fi 4 (802.11n)

Width

83 mm
