Power Supply BE QUIET ATX PC 100 - 240 V 1200 W BP021EU

80 PLUS certification

80 PLUS Titanium

AC input frequency

50

AC input voltage

100 V

ATX power connector (20+4 pin)

+

ATX version

3.1

Bearing technology

FDB

CPU power cable length

700 mm

CPU power connector (4+4 pin)

+

Cable ties included

+

Cabling type

Fully-Modular

Combined power (+3.3V)

120

Combined power (+5V)

120

Combined power (+12V)

1200

Compliance certificates

CB/cTUVus/Federal Communications Commission (FCC)/RoHS/TÜV mark/UKCA/WEEE

Cooling type

Active

Depth

175 mm

EPS power connector (4+4 pin)

+

EPS power connector (8-pin)

+

EPS version

2.92

Efficiency

93.1

Fan diameter

135 mm

Fan speed

0

Height

86 mm

Hold time

19.5 ms

Manual

+

Manual languages

English/French/German/Italian/Japanese/Polish/Russian/Simplified Chinese/Spanish/Thai/Ukrainian

Maximum input current (@110V)

10

Maximum input current (@220V)

5

Max output current (+3.3V)

25

Max output current (+5V)

24

Max output current (+5Vsb)

3

Max output current (+12V1)

33

Max output current (+12V2)

33

Max output current (+12V3)

45

Max output current (+12V4)

45

Max output current (-12V)

0.5

Mean time between failures (MTBF)

100000

Motherboard power cable length

600 mm

Motherboard power connector

20+4 pin ATX

Noise level

21.1 dB

Number of +12V rail(s)

4

Number of SATA power cables

13

Number of fans

1

On/off fan switch

+

On/off switch

+

Operating temperature (T-T)

0

PCI Express connector

+

PCI Express power cable length

600 mm

PCI Express power connectors (6+2 pin)

4

PCI Express power connectors (12-pin)

2

Package depth

126 mm

Package height

355 mm

Package weight

3700 g

Package width

230 mm

Peak power

1300

Peripheral (Molex) power cable length

1050 mm

Peripheral (Molex) power connectors (4-pin)

2

Power factor

0.98

Power protection features

Over current/Over voltage/Overheating/Overload/Short circuit/Surge & inrush protection (SIP)/Under voltage

Power supply unit (PSU) form factor

ATX

Product colour

Black

Products per shipping (inner) case

4

Purpose

PC

SATA power cable length

1050 mm

Screws included

+

Shipping (inner) case height

260 mm

Shipping (inner) case length

528 mm

Shipping (inner) case net weight

20140 g

Shipping (inner) case width

368 mm

Summary

be quiet! Dark Power 14 1200 W - 80 Plus Titanium. Total power: 1200 W, AC input voltage: 100 - 240 V, Peak power: 1300 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 600,750,900,1050 mm.

Sustainability certificates

ENERGY STAR/ErP/Triman

Total power

1200

Unit Calculated Volume

0.01 cubm

Weight

2300 g

Width

150 mm
