Listwa N+PE stostowana w rozdzielnicach RH NEOseries

Closing plate required

+

Connectable conductor cross section fine-strand with cable end sleeve

1.5 .. 16 mm²

Connectable conductor cross section solid-core

1.5 .. 16 mm²

Depth

18 mm

Drill hole distance centrically

172 mm

Explosion-tested version 'Ex e'

-

Halogeenivaba

+

Kõrgus

26 mm

Laius

190 mm

Material insulation body

Thermoplastic

Mounting method

Direct mounting

Number of clamp positions per pole

9

Number of poles

2

Operation temperature

-20 .. 60 °C

Rated current In

120 A

Rated voltage

500 V

Transparent

-

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection

Värv

Other
