Current control relay RM17-J, range: 2..20A. range of product: Zelio Control - product or component type: modular measurement and control relays - relay type: current control relay - relay name: RM17JC - switching capacity in VA: 1250 VA - utilisatio

Contains function DC-voltage over current

-

Contains function DC-voltage under current

-

Current measurement range

2 .. 20 A

Depth

72 mm

External current transformer

-

External power supply required

-

Function DC-current hysteresis

-

Kõrgus

90 mm

Laius

17.5 mm

Max. permitted delay-on energization time

0.5 s

Number of contacts as change-over contact

1

Number of contacts as normally closed contact

0

Number of contacts as normally open contact

0

Rated control supply voltage Us at AC 50HZ

24 .. 240 V

Rated control supply voltage Us at AC 60HZ

24 .. 240 V

Rated control supply voltage Us at DC

24 .. 240 V

Single-phase hysteresis possible

-

Single-phase over current possible

+

Single-phase under current possible

-

Three-phase hysteresis possible

-

Three-phase over current possible

-

Three-phase under current possible

-

Type of electric connection

Screw connection

Voltage type for actuating

AC/DC

Voltage type of supply voltage

AC/DC

With detachable clamps

-
