Miniature Plug-in relay, Zelio RXM 2 C/O 24 V DC 12A. range of product: Zelio Relay - series name: Miniature - product or component type: plug-in relay - device short name: RXM - contacts type and composition: 2 C/O - status LED: without - control ty

Complete with socket

-

Degree of protection (IP)

IP40

Depth

55 mm

Drive, polarization

Polarity free

Drive, switching attitude

Mono stable

Kõrgus

27 mm

Laius

21 mm

Material contact

Other

Material of contact insert

Other

Material of contact surface

Other

Nominal current

12 A

Number of contacts as change-over contact

2

Number of contacts as normally closed contact

0

Number of contacts as normally open contact

0

Rated control supply voltage Us at AC 50HZ

0 .. 0 V

Rated control supply voltage Us at AC 60HZ

0 .. 0 V

Rated control supply voltage Us at DC

24 .. 24 V

Type of electric connection

Plug-in connection

Type of switch contact

Other

Voltage type for actuating

DC

With LED indication

-

With detachable clamps

-

With forced-guided contacts

-
