Red complete illuminated selector switch Ø22 2-position stay put 1NO+1NC 24V. range of product: Harmony XB5 - device short name: XB5 - mounting diameter: 22 mm - shape of signaling unit head: round - contacts type and composition: 1 NO + 1 NC - conta

Colour button

Red

Colour front ring

Black

Degree of protection (IP)

IP66

Degree of protection (NEMA)

13

Height opening

- mm

Hole diameter

22.5 mm

Material front ring

Plastic

Number of contacts as change-over contact

0

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

Number of switch positions

2

Spring-return

-

Suitable for illumination

+

Supply voltage

24 .. 24 V

Switching function latching

+

Type of control element

Short thumb-grip

Type of electric connection

Screw connection

Width opening

- mm

With front ring

+

With light source

+
